SPECIFICATIONS

Application: Metering

Brand Name: kamoer

Certification: CE,RoHS

Diaphragm Liquid Pump Flow rate: ELP02≥600ml/min

Diaphragm Liquid Pump Motor: Brush motor

Diaphragm Liquid Pump Voltage: 12V/24V

Diaphragm Liquid Pump Weight: about 215g

Fuel: Electric

Head: ≥20m

High-concerned chemical: None

Lifetime: over 1000H

Material: EPDM

Model Number: ELP02 Diaphragm Liquid Pump

Origin: China Mainland

Power (W): Electric

Power Source: Electric

Pressure: Low Pressure

Standard or Nonstandard: Standard

Structure: Diaphragm Pump

Suction: ≥2m

600ml/min ELP02 Mini Diaphragm Liquid Pump with 12V/24V

Brush Motor Self Priming Pump for Liquid Transfer

Basic Parameters	ELP02
Flow ml/min	≥600ml
Suction	≥2m
Head	≥20m
Power	≤6W
Motor	Brush motor
Voltage	12V/24V
Noise	≤68dB (test environment noise ≤35dB, the horizontal distance between the test product and the noise meter is 0.5m)
Weight	≈215g
Control method	Switch control
Lifetime	≥1000H
Working environment	Temperature 0℃～50℃, relative humidity RH＜80%
Optional accessories	PU: ID4mmxOD6mm
Supplementary instructions	The above parameters are the test results under standard atmospheric pressure, room temperature 25°C, water medium, and no load pressure of the pump (no liquid drop). The performance parameters of the product are affected by the environmental state (air pressure, temperature, humidity, etc.), medium state (temperature, density, viscosity, chemical properties, etc.) and the load before and after the pump, so the above parameters may be different from the actual parameters.
